New Brunswick Excella E25 Incubator Shaker

The New Brunswick Excella E25 Incubator Shaker is a large capacity shaker that utilizes a UniCentric single eccentric counterbalanced drive to provide horizontal plane rotary motion in a 2.54 cm (1 in) circular orbit. The proportional/Integral (PI) microprocessor controller with instantaneous digital feedback controls the speed over a range of 50-400 rpm.The shaker also features a timed mode via a programmable timer for shaking periods of 0.1 hr. to 99.9 hrs.

All of our equipment will be fully tested to perform at factory specifications before being shipped.

INCLUDED:

The New Brunswick Excella E25 Incubator Shaker includes:

> NIST Calibration and Preventative Maintenance Report

> Power Cord

> Operator's Guide

> Full 180 Day Parts and Labor Warranty

New Brunswick Excella E25 Incubator Shaker Specifications

Shaking Speed :	50-400 RPM
Speed Control Accuracy :	1 RPM
Speed Indication :	3-digit LED, displayed in 1 rpm increments
Shaking Stroke/Orbit :	2.54cm (1in)
Temperature Ambient* Operating Environment :	10 - 35C, 20 to 80% relative humidity, non-condensing
Refrigerant :	R-134A
Alarms :	Visible and audible warning indication when speed deviates more than 5 rpm, and temperature more than 1C from setpoints, and when timer has expired.
Timer :	0.1 to 99.9 hours. Shuts off agitation at end of period. Can be deactivated for continuous operation.
Automatic Restart :	Automatic restart after power is restored. Setpoints and operating status are retained in memory during power interruption.
Drive Interrupt :	Automatic drive-interrupt when cover is opened.
Electrical Requirements :	110/120 VAC, 50/60 Hz 220/240 VAC, 50/60 Hz
Platform :	76 X 46 cm (30 X 18 in)
Overall Dimensions (W x D x H) :	127 cm X 77 cm X 85 cm (50 in X 30.5 in X 41.7 in)
Chamber Dimensions (W x D x H) :	85 cm X 58 cm X 48 cm clearance above platform (33.5 in X 23 in X 19 in)
Weight :	204.5 kg (450 lb)

New Brunswick Excella E25 Manual
