**Currently en route to our facility. It will take about 30 days to arrive, after which we will test and certify it.**

Included Items:

Thermo Scientific Microm HM550 P Cryostat Microtome

Blade Holder

Power Cable

Certified to Perform at Manufacturer Specifications

After your instrument arrives at our facility, it will be inspected and tested to certify it performs at manufacturer specifications. If any component does not pass testing, then it will receive the service necessary to restore full functionality.

Specifications

Manufacturer	Thermo Scientific
Model	Microm HM 550 P
Cat. No.	956424
Serial Number	45805
Place of Mfg.	Germany
Chamber Temperature Control	-10°C to -35°C
Specimen Temperature Control	+10°C to -50°C
Fine Sectioning Thickness	1 to 100 µm
Trim Sectioning Thickness	5 to 500 µm
Horizontal Feed	28mm
Vertical Stroke	60mm
Fast Freezing Station Depending on the Chamber Temperature	Up to -35°C
Actively Cooled Fast Freezing Station with Peltier Element	Max. Up to -60°C
Defrosting	- Automatic Defrosting, Adjustable with Temperature Control - Manual Immediate Defrosting
1 to 100 µm Resolution	1 µm from 1 to 10 µm 2 µm from 10 to 20 µm 5 µm from 20 to 70 µm 10 µm from 70 to 100 µm
Trimming Thickness Range	5 to 500µm
5 to 500 µm Resolution	5 µm from 5 to 10µm 10 µm from 10 to 100 µm 20 µm from 100 to 200 µm 50 µm from 200 to 500 µm
Specimen Retraction During Return Travel	40 µm
Vertical Specimen Stroke	60 mm
Horizontal Specimen Movement	28 mm
Specimen Approach	Automatic Function Alternatively Manual with variable speed
Size of Chunks	30 and 40 mm Special sizes upon request to manufacturer
Specimen Orientation	X- and Y-Axes: Universal 8° with zero positioning Z-Axis: Up to 360°
Coarse Feed	Motorized, Graduated, Single and Continuous
Sliding Window	Heated
Cooling Chamber Illumination	With Variable Illumination Position
Electrical Requirements	115V, 60Hz, 12A
Dimensions	30 x 25 x 47 in. (64 x 76 x 120cm)
