Prior 10 Position Motorized Filter Wheel HF110

The Prior Scientific filter wheel system can be provided as a
stand alone unit or used in conjunction with stage and focus systems controlled
via the Prior ProScan, Prior PCI II, or OptiScan stepper motor
controllers.

Prior Scientific products have an established reputation for quality and reliability. They are manufactured using high-quality components.

Specifications:

Filter Wheel
10 position, 25mm filters

Speed
55ms between adjacent positions

(120ms for OptiScanTMII)

Weight
3.2 kg (7 lbs)

Controller
Driven via ProScanTMII, PriorPCI2 or OptiScanTMII Controller

External Control
Optional Filter Wheel Keypad

* Specifications subject to change without notice

Features:

• The ability to mount on the illumination or emission side of the microscope

• Available for 25mm (10 position) or 32mm (8 position) filters

• A large selection of adapters to fit most illuminators

• Filter wheel position and shutter status are controlled via either RS232 or an optional keypad

• Filter wheels can be stacked together in series for ND filters

• Magnetic covers over the filter load position on both sides of the filter wheel for easy access to change filters

• Visible filter position numbers for both the light path filter and the load position filter

• Filter wheel stand for added stability

• Optional dual slide in neutral density filter holder

Dimensions:

'A' Maximum on stand 540mm

‘A’ Minimum on stand 34mm

‘A’ Minimum off stand 28mm

‘B’ for HF110 - 141mm

‘B’ for HF108 - 159mm

‘C’ for HF110 - 179mm

‘C’ for HF108 - 195mm
